National Item Identification Number
00-754-1791
007541791
5306-00-754-1791
5306007541791
National Stock Number
Item Name
BOLT,MACHINE
Federal Supply Class
5306
Referenced on: http://gasturbinegenerators.tpub.com//TM-5-6115-590-20P/css/TM-5-6115-590-20P_297.htm
Referenced on: http://gasturbinegenerators.tpub.com//TM-5-6115-590-20P/css/TM-5-6115-590-20P_356.htm
Referenced on: http://welding.tpub.com//TM-5-6115-590-34P/TM-5-6115-590-34P0362.htm
Referenced on: http://welding.tpub.com//TM-5-6115-590-34P/TM-5-6115-590-34P0564.htmDescription
An externally threaded fastener designed for insertion through holes in assembled parts and normally intended to be tightened or released by torquing a nut. The threaded and unthreaded portions are both of one nominal diameter of 0.190 inch (5 mm) or larger. The head is not designed to be held or driven with an inserted driver or by the thumb and fingers. A locking feature may be incorporated in the design of the head or threads. Head dimensions and sizes of threaded and unthreaded portions shall conform to internationally recognized fastener standards. For items having a grip length portion machined to a tolerance of 0.0015 inch (0.038 mm) or less, BOLT, SHEAR. See also SCREW, CAP, HEXAGON HEAD and SCREW, MACHINE.
Commercial and Government Entity Code (Supplier Data)
99167
31361
66503
NSN (National Stock Number) 5306-00-754-1791, 5306007541791 NIIN (National Identification Number) 00-754-1791, 007541791
Part Numbers (Reference Numbers)
AN73-5
MS20073-03-05
0904-105
190586
190586
Required Categories
THREAD SERIES DESIGNATOR
NOMINAL THREAD DIAMETER
THREAD QUANTITY PER INCH
THR
Required Description
UNF
0.190 INCHES
32
3A
RIGHT-HAND
0.499 INCHES MINIMUM AND
0.578 INCHES MA
