National Item Identification Number
00-270-7390
National Stock Number
Item Name
BOLT,MACHINE
Federal Supply Class
5306
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-288-34P/TM-5-3810-288-34P0401.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-288-34P/TM-5-3810-288-34P0780.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-288-34P/TM-5-3810-288-34P0826.htmDescription
An externally threaded fastener designed for insertion through holes in assembled parts and normally intended to be tightened or released by torquing a nut. The threaded and unthreaded portions are both of one nominal diameter of 0.190 inch (5 mm) or larger. The head is not designed to be held or driven with an inserted driver or by the thumb and fingers. A locking feature may be incorporated in the design of the head or threads. Head dimensions and sizes of threaded and unthreaded portions shall conform to internationally recognized fastener standards. For items having a grip length portion machined to a tolerance of 0.0015 inch (0.038 mm) or less, BOLT, SHEAR. See also SCREW, CAP, HEXAGON HEAD and SCREW, MACHINE.
Commercial and Government Entity Code (Supplier Data)
95201
NAPCO INTERNATIONAL LLC
11055 EXCELSIOR BLVD
HOPKINS
MN
55343
952-931-2490
3D6E9
AXLE TECH INTERNATIONAL INC
3001 WEST BIG BEAVER 400
TROY
MI
48084
248-244-9724
78500
MERITOR HEAVY VEHICLE SYSTEMS LLC
DBA MERITOR WABCO VEHICLE CONTROL
2135 W MAPLE RD
TROY
MI
48084
859-525-3764
23862
MILITARY VEHICLES OPN
GENERAL MOTORS TRUCK AND BUS GROUP
660 S BOULEVARD E
PONTIAC
MI
48341
248-456-5000
24617
19207
NSN (National Stock Number) 5306-00-270-7390, 5306002707390 NIIN (National Identification Number) 00-270-7390, 002707390
Part Numbers (Reference Numbers)
11A8295
15X112
15X112
16613F
2035371
2035371
36617J
8330308
90826
Required Categories
THREAD SERIES DESIGNATOR
NOMINAL THREAD DIAMETER
THREAD QUANTITY PER INCH
THR
Required Description
UNF
0.562 INCHES
18
3A
RIGHT-HAND
0.812 INCHES MINIMUM
2.562 INCHES NOMINA
