National Item Identification Number
01-209-7017
012097017
5306-01-209-7017
5306012097017
National Stock Number
Item Name
BOLT,MACHINE
Federal Supply Class
5306
Description
An externally threaded fastener designed for insertion through holes in assembled parts and normally intended to be tightened or released by torquing a nut. The threaded and unthreaded portions are both of one nominal diameter of 0.190 inch (5 mm) or larger. The head is not designed to be held or driven with an inserted driver or by the thumb and fingers. A locking feature may be incorporated in the design of the head or threads. Head dimensions and sizes of threaded and unthreaded portions shall conform to internationally recognized fastener standards. For items having a grip length portion machined to a tolerance of 0.0015 inch (0.038 mm) or less, BOLT, SHEAR. See also SCREW, CAP, HEXAGON HEAD and SCREW, MACHINE.
Commercial and Government Entity Code (Supplier Data)
86403
CHRYSLER CORP
SERVICE AND PARTS OPNS
26311 LAWRENCE AVE
CENTER LINE
MI
48015
586-497-0999
NSN (National Stock Number) 5306-01-209-7017, 5306012097017 NIIN (National Identification Number) 01-209-7017, 012097017
Part Numbers (Reference Numbers)
6024067
Required Categories
Required Description
